Protection caps

Protection caps

IP67 and IP53

Protection caps

IP67 and IP53

The PowerSyntax IP67 caps ensure complete waterproof protection and IP53 caps area  fast, easy way to protect connectors.

  • IP67 Protection caps

    IP67 Protection caps

    The PowerSyntax IP67 caps ensure complete waterproof protection.

    The PowerSyntax IP67 caps ensure complete waterproof protection.

    The PowerSyntax caps are universally keyed to be fitted on any connector’s phase, so that just one cap version is needed respectively for Source and Drain connectors resulting in easier management and lower investment through reduced stock assortment. For full safety, the PowerSyntax IP67 caps feature the secondary locking system. The secondary lock will be released using SyntaxLock or a standard release key.



  • IP67 protective cover   for source

    IP67 protective cover
    for source

    IP67 protective cover
    for source

  • IP67 protective cover   for drain

    IP67 protective cover
    for drain

    IP67 protective cover
    for drain

  • Special housing on caps for lacing

    Special housing on caps for lacing

    Special housing on caps for lacing

    Lacing through special high-resistance cable made up of seven stainless strands, and covered by anti-scratch teflon black tubing.

  • IP53 Protection caps

    IP53 Protection caps

    The IP53 caps are fast, easy way to protect PowerSyntax connectors

    The IP53 caps are fast, easy way to protect PowerSyntax connectors

    The use of protective caps results in:
    - Extended life span of the connectors as the mating faces are protected against impact damage and abrasion
    - Improved safety as contacts are protected against dust and water even when the connectors are not mated

  • IP53 protective cover   for source

    IP53 protective cover
    for source

    IP53 protective cover
    for source

  • IP53 protective cover   for drain

    IP53 protective cover
    for drain

    IP53 protective cover
    for drain

  • Protection caps lacing

    Protection caps lacing

    Protection caps lacing

    On the PowerSyntax caps, all details have been designed with a strong focus on resistance and reliability. A specific housing for the cap’s lacing has been moulded directly on the flange of the panel-mount versions and on the body of the inline versions. The caps are laced to the connector’s body through a special high-resistance cable made up of seven stainless strands, and covered by anti-scratch teflon black tubing.
