    The PowerSyntax Chain Pilot box features a set of PowerSyntax Chain Pilot connectors with L1+L2+L3+N+PE (or L1+L2+L3+PE), each one with its built-in microswitch. The connector’s microswitches control an auxiliary circuit connected to an external device (breaker, contactor, etc.), so that the system will only be activated once all the mechanically keyed cable connectors have been inserted in the corresponding panel-mount connectors on the Chain Pilot Box. So there is no need to respect a sequential order when mating or unmating your connectors, unlike on other Powerlock-compatible boxes.
    All connectors will de-energise should one become disconnected when in use.

  • Product overview

    Product overview


    Insert all the cable connectors to activate the breaker or protection device.
    All connectors will de-energise should one become disconnected when in use.
    Built-in microswitch for electrical interlock on all connectors.
    No mechanical locks / longer lifespan.
    Ensures safe connection of all phases, neutral and earth.
    Electrical safety guaranteed.
    International patent on connectors


    Supply notice
    Environmental caps supplied as a standard to ensure IP67 even when connectors are unmated.

  • Technical features

    Technical features


    Intermateable with standard PowerSyntax or other powerlock-style connectors.
    Microswitch-controlled auxiliary circuit ensures that the system will only be energised when all 5 connectors on the box have been mated.
    Total electrical safety as all connectors are de-energised should one become disconnected.
    Color coded connectors.
    5-pole (E-N-L1-L2-L3) or 4-pole (E-L1-L2-L3) system with Panel Drain or Source connectors.
    Mechanically keyed connectors to prevent mating errors.
    Secondary lock for added mechanical safety.
    IP2X finger-proof protection.
    2U 19” rack-mountable box.
    IP67 rating on connectors’ front mating side.
    Microswitch-controlled auxiliary circuit ensures that the system will only be energised when all connectors on the box have been mated.

  • PowerSyntax Chain Pilot box panel front
  • PowerSyntax Chain Pilot box - Panel rear with contacts
  • Technical data

    Technical data

    Rated current:480amp or 750amp
    Rated voltage:1000V AC / 1500V DC
    Color coding:EUROPE: color coded connectors and panel inscriptions (E-green, N-blue, L1-brown, L2-black, L3-grey)
    UK (old): color coded connectors (E-green, N-black, L1-red, L2-yellow, L3-blue)
    AUSTRALIA: color coded connectors (E-green, N-black, L1-red, L2-white, L3-blue)
    USA: color coded connectors (E-green, N-white, L1-black, L2-red, L3-blue)
    Model:source or drain
    Contact material:silver plated copper
    Box material:high temperature thermoplastic
    Rack space:2U or 2.5U
    Endurance:500+ connection cycles
    Degree of protection (connectors front side):IP67 when mated of with environmetal caps fitted (IP67 caps supplied as a standard)
    Degree of protection (connectors without caps):IP2X finger-proof
    Flammability:UL94 - V0
    Operating temperature:-30°C to +85°C
    Safety notice:The PowerSyntax chain pilot box should only be installed and operated by suitably qualified persons
