PowerSyntax panel connectors - 480amp & 750 amp - Powerlock compatible

PowerSyntax
panel connectors

With Microswitch, Basic
or Shelter versions

PowerSyntax
panel connectors

With Microswitch, Basic
or Shelter versions

Panel source and panel drain single pole connectors for high currents, Powerlock compatible.

  • Looking for high current
    panel connectors?

    Looking for high current
    panel connectors?

    Discover our innovative, Powerlock compatible, single pole panel connectors: 3 options that will improve your productivity while bringing you peace of mind on all electrical insulation and safety-related issues. And no compromises on connectors' design and performances.

  • Syntax, no compromise.

  • Chain Pilot

    Chain Pilot

    Panel connector with microswitch
    480 or 750 amp

    Panel connector with microswitch
    480 or 750 amp


  • PowerSyntax Chain Pilot -  Panel connector with built in Microswitch - Powerlock compatible


    This version of the panel-mount PowerSyntax connectors has a built-in pilot microswitch.
    The Chain Pilot has been designed to obtain protective electrical interlocking (or additional controls) through a chain of simultaneously operating connectors (see circuit diagrams in the product page). The electrically interlocked connectors will all de-energise should one become disconnected when in use, making it impossible that any connector is removed under load. Drain and Source versions available, for currents up to 480amp or up to 750amp.

  • Basic

    Basic

    Classic SPX panel connector
    480 or 750 amp

    Classic SPX panel connector
    480 or 750 amp

  • PowerSyntax Basic single pole panel connectors - 480amp & 750 amp - Source & drain

    Panel source and drain

    Panel source and drain

    The Basic SPX PowerSyntax panel-mount connectors are available as an alternative to the new Chain Pilot with in-built microswitch.Specific housing for protection cap lacing moulded on the connector's flange. IP2X protection through patented drain contact lock. Secondary locking safety system. Permanent phase identification and safety information markings embossed on connector’s shell. No stickers applied. Drain or Source versions,  available for high currents up to 480amp or 750amp.

  • Shelter

    Shelter

    Panel connector with protective backshell

    Panel connector with protective backshell

    PowerSyntax Shelter -  Panel connectors with backshell - Powerlock compatible

    Shelter panel-mount PowerSyntax connectors provide total insulation and watertight protection on the cable-to-connector joints on the back of your panels. The range features 3 models of thermoplastic insulating backshells that are machined and designed to combine with various contact types. The system includes an IP68 gland for cable strain relief, creating an actual shelter that provides a range of ideally-sized mechanically strong solutions for IP67 watertight seal at the cable-to-contact connection.

  • Drain contact
    IP2X safety lock

    Drain contact
    IP2X safety lock

  • Drain contact IP2X patented safety lock

    Our innovative mechanical lock prevents improperly pushing the contact inwards with fingers or tools!

    Our innovative mechanical lock prevents improperly pushing the contact inwards with fingers or tools!

  • New threaded IP2X protection

    New threaded IP2X protection

    New threaded IP2X protection

    For source contacts

    For source contacts

    Thanks to this new design, a portion of the source contact's insulating cap will remain in its position on top of the source contact even in case of damage, improving the overall safety for the user.

  • Optional M5   threaded fittings

    Optional M5
    threaded fittings

    Optional M5
    threaded fittings

    To order the optional M5 threaded fittings for rear panel mount select the code M5 when compiling the Part Number form.

  • The best connectors
    deserve the best accessories.

    The best connectors
    deserve the best accessories.

    Discover how to make a great product even better

    Discover how to make a great product even better

  • SyntaxLock

    SyntaxLock

    SyntaxLock

    Patent pending

    Patent pending

    Suitable for all PowerSyntax connectors. Can be fitted or removed at any time. A simple, universal accessory. Quick and easy to install.

  • Protection caps IP67

    Protection caps IP67

    Protection caps IP67

    For IP67 waterproof protection

    For IP67 waterproof protection

    The PowerSyntax IP67 caps ensure complete waterproof protection and IP53 caps are a fast, easy way to protect connectors.
